DiMAX FB Train Detection Module

Massoth 8170510 DiMAX FB Train Detection Module

The 8170510 monitors four independent track sections and flags them occupied when a train is present. The trip current is adjustable in five steps (~2–100 mA). It handles 6 A continuous per section (8 A peak) and 8 A total (12 A peak). Occupancy is reported via the DiMAX Feedback Module or shown directly with LEDs; also suitable for booster and reverse-loop applications.
